Six-Sided Top Press Systems for Synthetic Diamond, Cultured Diamond and Superhard Materials六面顶压机整机与整线方案
人造金刚石 · 培育钻石 · 超硬材料高温高压合成装备

Synthesis Principle合成原理

Simulating a billion years of nature in seven days把自然界的亿万年生长，压缩到 7 天

Natural diamond forms deep in the earth's mantle under extreme pressure and temperature. The six-sided top press reproduces that environment inside a sealed synthesis cell — six anvils advance simultaneously on the cube, generating a uniform pressure field of about 5–6 GPa at 1300–1500 °C. High-purity graphite and metal catalyst layers then recrystallise into diamond, with a full growth cycle completing in roughly seven days.天然金刚石形成于地幔深处的高温高压环境。六面顶压机在密闭合成腔体中复现这一条件：六个顶锤沿立方体六个方向同步推进，在腔体内建立约 5–6 GPa、1300–1500 °C 的均匀压力温度场，高纯石墨与金属触媒层在触媒作用下重结晶为金刚石，完整生长周期约 7 天。

• Six-way synchronized loading — equal thrust on all six anvils keeps the cell pressure balanced and the crystal shape complete.六向同步加压——六个顶锤同步推进、推力均衡，腔体压力场对称，晶体生长形态完整。
• Sealed synthesis cell — pyrophyllite / dolomite cell assemblies contain the reaction and control heat loss.密闭合成腔体——叶蜡石 / 白云石复合腔体组件承载反应，并控制热量散失。
• Precise thermal control — heating power is closed-loop regulated to hold the growth window for the full cycle.精确温度控制——加热功率闭环调节，在整个生长周期内稳定保持在工艺窗口内。
• Automatic pressure holding — the system compensates for cell deformation and keeps pressure drift minimal.全自动稳压保压——系统自动补偿腔体形变，将压力漂移控制在极小范围。
• 200+ parameters logged — pressure, power, stroke and temperature curves are recorded per cycle for traceability and yield analysis.200+ 参数记录——每周期压力、功率、行程、温度曲线完整留存，可用于溯源与良率分析。
